MIDISPAN

Midispan is our longspan racking system with steel decking panels. The pre-galvanised finish is perfect for demanding environments.

SCROLL DOWN



Midispan is our longspan shelving system
with steel decking panels supplied in a contemporarypre-galvanised finish.

This makes it ideal for the most demanding applications and environments. The profiles are designed in such a way to ensure there are no sharp edges when assembling or in use. The system has a wide range of profiles and sizes which provides complete flexibility when designing your warehouse. Along with a range of accessories that make it simple to store many different products as well as bespoke solutions for the automotive industry.



We offer guaranteed delivery within 5 days, including components to build a high bay or multi-tier installation from our large stocks.

Heights

Heights (mm)
M50 Profile

1950, 2550, 3000



M70 Profile
2550, 4500, 5550, 6000

Widths

Widths (mm)
C50 Beams

1000, 1200, 1600



C70 Beams

1000, 1200, 1600, 1800, 2000, 2400

C100 Beams

1600, 1800, 2000, 2400

Depths

Depths (mm)
400, 600, 800, 1000, 1200

Application

Environment

Warehouse, Storeroom, Workshop



Usage

Heavy Duty Storage
Automotive Storage Solutions

Construction

Uprights: Steel
Galvanised

C50 & C70 Beams: Steel

Galvanised

C100 Beams: Steel
Grey RAL7037

Shelves: Steel
Galvanised Panels

Loadings

Shelf Load up to
750kg UDL



M50 Max Bay Load

4300kg

M70 Max Bay Load

8800kg

Contact sales office for
complete loading info
